| DMP 331P | stainless steel sensor (flush) hygienical application |
| The pressure transmitter DMP 331P was designed for use in the food and pharmaceutical industry. The compact design with hygienic process connections makes it possible to achieve an outstanding performance in terms of accuracy, temperature behavior and long term stability. | |
| The modular construction concept allows a combination of various process connections with different filling fluids and a cooling element. Several electrical connections complete the profile of DMP 331P. This transmitter fulfills nearly all requirements in hygienic industrial processes. | |
| Features | nominal pressure: 0 … 100 mbar up to 0 … 40 bar |
| accuracy: 0.35 % (opt. 0.25 %) FSO | |
| CIP / SIP cleaning up to 150 °C | |
| vacuum resistant | |
| hygenic version | |
| diaphragm with low surface roughness | |
| Optional Features | IS-version Ex ia = intrinsically safe for gases and dusts |
| SIL 2 according to IEC 61508 / IEC 61511 | |
| cooling element for media temperatures up to 300 °C | |
| diaphragm in Hastelloy® or Tantalum |
