GMB range

Detail Georgin offers a remote input solution for standard applications.
Specificities: » Simplified configuration by Switch
  » Power and Modbus through the rear connector
Module reference: » GMB 96100 – Module with 1 standard analog input (AI)
       – 0/4 … 20 mA
       – 0/2 … 10 V
       – 0/1 … 5 V
       – Transmitter power supply up to 16V @ 20mA
  » GMB 96200 – Module with 4 universal analog inputs (AI)
       – 0/4 … 20 mA
       – 0/2 … 10 V
       – 0/1 … 5 V
  » GMB 96500 – Module with 1 universal analog input (AI)
       – Pt, Ni, TC, KTY, R, Pot
       – mV, V, mA DC/TRMS
       – Frequency, PWM
       – Transmitter power supply up to 16V @ 20mA
  » GMB 96700 – Module with 4 logical Inputs / Outputs (DI/DO)
       – Each channel can be parameterized as input or output
             » Input: 5 V / 12 V / 24 V
             » Output: 30 V / 100 mA
  » GMB 96800 – Module with 4 independent relays (DO)
       – Switching power of relays
             » 250 V AC / 30 V DC / 2 A
