This card is designed to interface and convert signals coming from the safe to the hazardous area. |
Input: |
Current (4/20mA – 0/20mA…), Voltage (0/5V – 0/10V…) or other on request |
Output: |
Current (4/20mA) |
Supply: |
24 VDC, 48 VDC, 110 VAC or 230 VAC |
Model: |
2 channels |
Setting: |
Adjustment potentiometer for the source and the curve |
green LED |
for presence of voltage |
installation: |
Safe area |
Options: |
» Hart signal transparency with the barrier (LWOI) |
|
» With or withoutkeying pin |
EC Type examination certificate number : |
LCIE03 ATEX 6469X |
ATEX/IECEx classification : |
II (1) GD [Ex ia] IIC ou [Ex ia] IIB ou [Ex iaD] |
